Product Introduction:
Dual-axis shredder all adopt microcomputer intelligent control system, set up start, stop, reverse and overload automatic reverse control functions, with low speed, large torque, low noise and other characteristics. The bearing seat adopts the split type, which is easy to disassemble and change the knife and suitable for shredding large, extra-thick and difficult materials. Shredder tool material is high-density alloy tool steel and high wear-resistant abrasive steel, durable; The reducer adopts the national standard series of hard tooth surface, the motor adopts the well-known brand, and the whole machine has a one-year warranty.
Dual-shaft shredder scope of application:
1, all kinds of plastics: plastic bags, plastic bottles, plastic drums, film, foam, PVC pipe, PVC sheet, plastic, woven bags, tons of bags, etc
2, all kinds of metals: scrap steel, scrap iron, aluminum alloy, iron pin, iron filings, spent iron, iron shavings, color steel tile, steel plate, steel bar, iron sheet, iron wire, etc
3, all kinds of wood: branches, trunks, roots, tree wheels, roots, wooden pallets, waste templates, waste furniture, etc
4, waste tires: car tires, truck tires, etc
5, scrap car body: car shell, bicycle, motorcycle, tricycle, etc
6, waste household appliances: refrigerators, televisions, washing machines, computers, circuit boards, electronic components, etc
7. Kitchen waste, household waste, animal carcasses, RDF derivatives, medical waste, biological orange stalks, garden waste, etc
8, paper mill waste, factory waste, waste paper books, cans, glass bottles, leather, cloth, etc.
Working principle
Biaxial shredder also known as shear shredder through cutting, tearing and extrusion to reduce the size of the material, this shredder is widely used in scrap metal, waste plastic, waste rubber tires, wood and other large volume waste. For China's waste recycling industry, to provide early crushing capacity reduction treatment. The thickness of the tool and the number of claws can be changed according to different materials and discharge particle size. Crushing hollow materials can be equipped with a press device to increase production, crushing tires can be equipped with a screen to ensure the granularity of discharge.
Technical parameter
| Model | Size(mm) | Size of crushing chamber(mm) | Blade diameter(mm) | blade thickness(mm) | Number of blades | Power(kw) | Weight(kg) |
|---|
| SZ-500 | 2800×1300×1850 | 500×480 | 200 | 20 | 24 | 11×2 | 2200 |
| SZ-800 | 3000×1300×1850 | 800×480 | 200 | 20 | 40 | 15×2 | 2500 |
| SZ-1000 | 3300×1900×2200 | 1000×690 | 300 | 40 | 24 | 22×2 | 5200 |
| SZ-1200 | 3600×2000×2200 | 1200×690 | 300 | 40 | 30 | 30×2 | 6400 |
| SZ-1500 | 4180×2100×2400 | 1500×850 | 550 | 50/75 | 30/20 | 37×2 | 9000 |
| SZ-1800 | 5800×2400×3300 | 1800×1206 | 550 | 50/75 | 36/24 | 55×2 | 13600 |
| SZ-2000 | 6400×2700×3500 | 2000×1490 | 600 | 50/75 | 40/26 | 75×2 | 20100 |
| SZ-2500 | 7500×3200×3800 | 2500×1800 | 600 | 75/100 | 32/24 | 110×2 | 25000 |
| SZ-3000 | 8600×3500×4000 | 3000×1800 | 600 | 75/100 | 40/30 | 160×2 | 31000 |
| Note: 1. The number, diameter and thickness of blade claws can be customized according to material type and discharge size; 2. Different types of materials and discharge sizes, equipment output will be different. |
